Model #: 3PAMSH24B-SZO

24,000 BTU Single Zone Outdoor Unit – Forest Series 230V

Zoned comfort is popular for a very important reason: energy efficiency. With this ductless unit from Perfect AireⓇ, you’re on your way to a zoned system that allows you to independently control the temperature of a single room from the rest of the house. Without the interference of clunky, dust-trapping ducts, heat and air go right to the space where it’s needed most. The 24,000 BTU mini-split unit is easy to install and operate, equipped with smart programmable modes and a handy remote that puts the thermostat at your fingertips.

Comes with a remote control with built-in room temperature sensor
Turbo operation
Heat pump for year round comfort
Self-diagnostic function
Sleep mode
Anti-cold air
Hydrophilic Aluminum Fin
Golden Fin
Low Ambient Kit
Auto Defrosting
Refrigerant Leakage Detection

Independently control the temperature of a single room from the rest of the house with this ductless unit from Perfect Aire®. That’s zoned comfort.

Features
Specs
Warranty
Resources

360° Air Flow Panel

Provides equal, fast and wide-range cooling in all directions

Turbo Operation

Unit maximizes cooling or heating output capacity to attain desired temperature in the shortest amount of time

Heat Pump

Provides year round comfort allowing unit to reverse refrigerant process in cold weather, by extracting outside heat and transferring inside. Excellent for house additions without forced air heating systems or where ductwork is not possible

Anti-Cold-Air

Prevents cold air from blowing out at the beginning of operation by automatically regulating fan speed according to temperature

Sleep Mode

Automatically increases (cooling) or decreases (heating) 2°F/hour for first 2 hours, and holds steady for next 5 hours before switching off and returning to preset temperature for both energy savings and comfort

Hydrophilic Aluminum Fin

Improves indoor unit cooling efficiency by enabling unrestricted flow of condensate water between aluminum fins and Improves outdoor unit heating efficiency by accelerating defrosting process

Golden Fin

Anti-corrosive coating on indoor and outdoor units withstands salty air, rain and other corrosive elements while improving heating efficiency by accelerating defrosting process

Low Ambient Kit

With a special built-in kit the air conditioner can be used in temperatures as low as 5°F for cooling

Self-Diagnostic Function

Detects abnormal operations or part failures, display an error code on the indoor unit, and switch off automatically to protect the system. Displays EC error code on indoor unit if outdoor unit detects refrigerant leak condition

Auto Defrosting

Evaporator automatically defrosts, prolonging product life and improving energy savings

Refrigerant Leakage Detection

Displays EC error code on indoor unit if outdoor unit detects refrigerant leak condition

Follow Me Remote Control

Comes with a remote control with built-in room temperature sensor regulates room temperature around remote and allows the remote to become a thermostat

Silver Ion Filter

Nano Silver attached to filter releases Silver Ion to kill or deactivate bacteria

Outdoor Unit Dimensions

Depth: 14 in
Width: 35 in
Height: 26.5 in

Package Dimensions

Depth: 16.25 in
Width: 39.5 in
Height: 29.5 in

Outdoor Unit Weight

Net: 104.5 lbs
Gross: 123 lbs

Full System Cooling Capacity

BTU: 24,000

Mini-Split Limited Warranty

INITIAL 30 MONTH WARRANTY

Confident in the quality of our products and their performance, we stand behind our products with an outstanding Initial 30 Month Warranty. If any part of your unit proves to be defective due to material and/or improper workmanship, under normal conditions and use, during the first 30 months of its original installation. At our discretion, we will either replace the defective part, or the entire unit — at no cost.

7 YEAR PARTS WARRANTY

If any part of your unit proves to be defective due to material and/pr improper workmanship, under normal conditions and use, within seven years from the original date of installation. At our option, we will replace the defective part — at no cost.

7 YEAR COMPRESSOR WARRANTY

If the compressor of your unit proves to be defective due to material and/or improper workmanship, under normal conditions and use, within seven years from the original date of installation, we will replace the defective compressor — at no cost.

Need An Extended Warranty?

Got a problem? Let us take care of it. Our extended warranties offer great benefits:

Replacement Guarentee
Up to three years of coverage
No hidden fees or deductibles
30 days to purchase coverage

More Information

Register Your Product

Fill out our easy online form to register your product with our Customer Service team.

Warranty only valid with original proof of purchase
